Carb Rebuild Kit - Black Rubber O-Ring Placement

Post by zads » Thu Jul 17, 2014 11:42 pm

Hello,

I just got my carb rebuild kit and I have this rubber black o-ring, but am unsure where it goes. Any help is appreciated.

Thanks
Attachments
Carb Rebuild 1.jpeg
Carb Rebuild 1.jpeg (143.39 KiB) Viewed 2342 times
Carb Rebuild.jpeg
Carb Rebuild.jpeg (107.65 KiB) Viewed 2342 times
Top
Hahnda
honda305.com Member
Posts: 835
Joined: Wed Nov 02, 2005 2:36 pm
Location: Cameron, WI

Post by Hahnda » Fri Jul 18, 2014 7:54 am

I believe that is the one that goes on the air mixture screw. One of the screws in the kit has a groove in it. This oring should be in that groove.
Top
bonjour
honda305.com Member
Posts: 167
Joined: Sun Aug 08, 2010 10:56 am
Location: Holland

Post by bonjour » Fri Jul 18, 2014 10:09 am

Yep, must be the ring for the air screw.

It also makes sense if you think about it :)
