Fork disassembly questions

R100 · Post by **R100** » Thu Mar 12, 2015 4:01 pm

OK. Thanks G.
I can move it by tapping gently on a piece of soft pine. Probably grunge underneath. Have to be patient to keep it square to the tube.
Again - pen. oil and hot air, but that is for tomorrow.
What do you think about that spring length?

R100 · Post by **R100** » Thu Mar 12, 2015 4:15 pm

I got the ring off and cleaned without damage.
The chamfer was facing down. I would think it should face up to trap the snap ring ???

Hoosier Tom · Post by **Hoosier Tom** » Thu Mar 12, 2015 4:49 pm

R100 wrote: Also, my online shop manual gives a spring free length of 278.8mm. Mine measure 403mm (15 7/8").

My manual gives an overall standard length of 407.0 with a repair limit of 396.0. Looks like you are fine.

HT

R100 · Post by **R100** » Thu Mar 12, 2015 4:51 pm

Hoosier Tom wrote:
R100 wrote: Also, my online shop manual gives a spring free length of 278.8mm. Mine measure 403mm (15 7/8").
My manual gives an overall standard length of 407.0 with a repair limit of 396.0. Looks like you are fine.

HT

Which manual is that Tom?

Hoosier Tom · Post by **Hoosier Tom** » Thu Mar 12, 2015 5:43 pm

R100 wrote:Which manual is that Tom?

My Honda service manual C/CS/CB 72/77. I checked it against a Clymer manual I had and it was identical.

HT

R100 · Post by **R100** » Fri Mar 13, 2015 8:00 am

Hoosier Tom wrote:
R100 wrote:Which manual is that Tom?
My Honda service manual C/CS/CB 72/77. I checked it against a Clymer manual I had and it was identical.
HT

Is this the one you refer to?

Hoosier Tom · Post by **Hoosier Tom** » Fri Mar 13, 2015 8:52 am

That's it.

HT
